 FI104P Suffix-X
- Display : 10.4 inch
- Resolution : 1024 X 768 (XGA/60Hz)
- Brightness / Contrast : 400 nit / 1400
- Power input : DC12V
- Outline dimension(W X H X D mm) : 270.0 X 214.0 X 49.3
The Rear cover size for reference.
- Dimension(WR X
HR mm) : 243 X 187
 General Outline Dimension
|
Model
|
Video Input
|
Type of Touch Screen
|
Type of Touch Controller
|
Remarks
|
|
FI104PN-D-X01
|
VGA / DVI (HDMI)
|
N
|
N
|
VA
|
|
FI104PN-D-X11
|
VGA / DVI (HDMI)
|
N
|
N
|
TN
|
|
FI104PT-D-X01
|
VGA / DVI (HDMI)
|
Resistive
|
USB
|
VA
|
|
FI104PT-D-X11
|
VGA / DVI (HDMI)
|
Resistive
|
USB
|
TN
|
|
FI104PT-D-X02
|
VGA / DVI (HDMI)
|
PCAP
|
USB
|
2 Points /VA
|
|
FI104PT-D-X12
|
VGA / DVI (HDMI)
|
PCAP
|
USB
|
10 Points / TN
|
|
