All-in-one monitors equipped with Android mainboards are available in various options, ranging from 10.4 inches to large 55-inch displays depending on the model. They can be categorized into models suitable for industrial use, DID (Digital Information Display) & kiosks, and media applications.These mainboards can be applied to all of our manufactured open-frame, panel-mount, and custom-made models that employ capacitive touch screens.You can refer to our existing product list for drawings, as well as touch and display specifications.Additionally, besides the standard port configuration, extra ports and licenses available as mainboard options can be provided upon request.



Function&Interface

Detailed Description

RESOLUTION

1024X768 upto 1920X1080 (FHD)

TOUCH SCREEN

Projected Capacitive 10Point

POWER INPUT

DC12V

CPU

Cortex-A17 quad-core, up to 1.8GHz

DDR

LPDDR-III 2GB (4GB Optional)

STORAGE

16GB EMMC NAND chip (upto 128GB Omtional)

HDMI OUTPUT

HDMI 2.0 standard display interface supports

Speaker

8 Ohm 6W Dual Audio (Optional)

USB 2.0 Interface

2 USB-A (Optioanl 6-expandable USB)

Serial Port

4 TTL/RS-232 compatible (Optional)

Micro SD Card

Self-elastic micro SD card socket, up to 128GB capacity

WiFi

Built-in high performance SDIO interface WiFi module, support IEEE 802.11 b/g/n

Bluetooth

Built-in high performance UART interface BT module

Ethernet

10/100M Adaptive Ethernet RJ45 connector

Real Time Clock

Ultra-low-power RTC circuit (CR1220 battery) with timer and alarm functionalities

DC Input

Supports 9~15V wide voltage DC power input

Ambient Requirement

Working temperature 0°~70°, working humidity 0%~95% (non-condensing)

Android Version

Recommended Android 7.1 / 11



* If you would like more details, just click here
